Eaton 278607 FAZ-S2/1 zaštitna sklopka za vodove 2 A 230 V/AC

Marka Eaton

(0 ocen)

22,99 EUR

(= 173,22 kn)

Proizvajalčeva koda: 278607

EAN koda: 4015082786076

Registrirana blagovna znamka: Eaton

Ime proizvajalca: Eaton Electric GmbH

Naslov proizvajalca: Hein-Moeller-Str. 7-11

Poštna številka proizvajalca: 53115

Kraj proizvajalca: Bonn

Država proizvajalca: Germany

Telefon proizvajalca: +496951709895

Elektronski kontakt proizvajalca: https://www.eaton.com

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

RoHS-konforno	Da
Nazivna struja - zaokružena	2 A
Nazivna struja	2 A
Boja	višebojna
Sadržaj	1 St.
Nazivni napon	230 V/AC
Broj prekidne snage	10 kA
Broj polova	1
Voltage type	AC
Built-in depth	70.5 mm
Rated current	2 A
Rated voltage	230 V
Frequency	50-60 Hz
Release characteristic	Other
Rated insulation voltage Ui	440 V
Current limiting class	3
Overvoltage category	3
Pollution degree	2
Width in number of modular spacings	1
Explosion-proof	FALSE
Power loss	1 W
Degree of protection (IP)	IP20
Number of protected poles	1
Concurrently switching neutral conductor	FALSE
Connectable conductor cross section solid-core	1-25 mm²
Connectable conductor cross section multi-wired	1-25 mm²
Ambient temperature during operating	-25-75 °C
Flush-mounted installation	FALSE
Additional equipment possible	TRUE
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	0 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	0 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10 kA
Rated impulse withstand voltage Uimp	4 kV
Vrsta proizvoda	zaštitna sklopka za vodove
