H07V-K1x25RG100hblau vodič 100 m

(0 ocen)

769,00 EUR

(= 5.794,03 kn)

Kod proizvoda: 2984769
EAN: 2050009579920
Procijenjena isporuka:13.10.2026 - 15.10.2026

Opis

Fleksibilni PVC kabel za ožičenje, finožičani, za unutarnje ožičenje uređaja kao i za zaštićeno polaganje u i na svjetlima, u cijevima (na i ispod žbuke) ali samo za sustave zvona ili signalizacije, kabel nije prikladan za direktno polaganje ispod žbuke, temperatura ugradnje -5°C do +70°C

Ovaj tekst je strojno preveden.

Varnost izdelkov (GPSR)

Proizvajalčeva koda: H07V-K1x25RG100hblau

EAN koda: 2050009579920

Registrirana blagovna znamka:

Ime proizvajalca: Conrad Electronic SE

Naslov proizvajalca: Klaus-Conrad-Str. 1

Poštna številka proizvajalca: 92240

Kraj proizvajalca: Hirschau

Država proizvajalca: Germany

Telefon proizvajalca: +499604408787

Elektronski kontakt proizvajalca: [email protected]

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Dokumenti

Upute za rad i sigurnost 2984769 H07V-K1x25RG100hblau vodič 100 m

Tehnički podaci

Sadržaj	100 m
Proizvođač-br. dijela	H07V-K1x25RG100hblau
Tip	H07V-K1x25RG100hblau
Nominal cross section conductor	25 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Weight	260 kg/km
Flame retardant	No
Circuit integrity	None
Nominal voltage U	750 V
Shape of conductor	Round
Conductor material	Copper
Conductor category	Class 5 = flexible
Armouring/reinforcement	None
Permitted cable outer temperature during assembling/handling	5-70 °C
Permitted cable outer temperature after assembling without vibration	-5-70 °C
Core colour	Blue
Nominal voltage U0	450 V
Screen	FALSE
Number of cores	1
Insulation integrity	None
Max. permitted conductor temperature	70 °C
Protective barrier	None
Outer diameter approximate	8.9 mm
With protective conductor	FALSE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Low temperature resistant according to EN 60811-504+505+506	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	None
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Min. permitted bending radius, stationary application/permanent installation	45 mm
Twisted cores	FALSE
Cable geometry	Round
Certified for shipboard application	FALSE
Suitable as medium-voltage cable	FALSE
Suitable as high-voltage cable	FALSE
Certified as airport lighting cable	FALSE
Vrsta proizvoda	vodič
